PL-2500 is our premium heavy-duty loader for high-intensity heavy-load tasks at quarries, batching plants, bulk yards and ports. Its ultra-thick frame, reinforced cylinders and high-torque engine sustain continuous heavy loading of ore and bulk materials. It comes with a wear-resistant rock bucket and boasts greater traction than smaller models. The spacious cab reduces fatigue, and it navigates rough mine terrain well. Custom attachments are optional. Each unit passes strict heavy-load testing, with global spare parts supply and exclusive wholesale prices for overseas dealers.
The PL-2500 heavy-duty Wheel Loader is constructed for high-intensity heavy-load shoveling and transport. Fitted with thickened reinforced load arm, high-torque power engine and large-capacity bucket, it handles bulk material stacking inside spacious large warehouses effortlessly, while adapting to harsh outdoor environments at large sand yards, infrastructure construction sites and large farms. Heavy-duty wear-resistant components extend service life and maintain steady loading capacity, enabling reliable heavy material operation in all tough working scenarios and protecting operator safety at all times.
| Specification | |
| Rated Load | 2500kg |
| Engine Brand | Huadong 4108 Turbocharged |
| Rated Power | 99kw(135HP) |
| Wheelbase | 2590mm |
| Boom Thickness | 30mm |
| Max. Travel Speed | 35km/h |
| Machine Operating Weight | 4620kg |
| Main Dimensions | |
| Overall Dimensions(L*W*H) | 6500*2200*2900mm |
| Bucket Width | 2000mm |
| Unload Height | 3600/3800mm |
| Lifting Height | 5150mm |
| Performance | |
| Drive Mode | Four-wheel Drive |
| Gearbox | 265 Split-type Torque Converter (Dual High-Low Speed) |
| Axle | Heavy-Duty Jingang Axle |
| Tire Model | 16/70-24 |
| Operation Mode | Single Lever Operation |
| Cooling System | Hydraulic Oil Cooler |
