This 2.5 ton universal electric forklift meets diverse indoor and light outdoor handling needs with multiple load options. Battery-powered, it runs emission-free with low noise for warehouses, supermarkets and factories. Its high-capacity lithium or lead-acid battery supports full-shift continuous work. The reinforced steel frame and thick mast ensure stable 2.5 ton loading with solid anti-collision performance. User-friendly controls are easy for beginners. Fewer wearing parts reduce maintenance and operating costs, offering an energy-saving, durable and cost-effective long-term handling choice.
Pure electric drive without tail gas pollution, suitable for food, medicine, closed warehouse and other high-environmental-standard workshops; low running noise improves working comfort.High-density battery configuration supports long-hour continuous work, avoids frequent charging interruptions, effectively improves site turnover efficiency.Thickened chassis, solid frame and thickened door frame structure, strong shock resistance, long service life, adapt to frequent daily heavy handling.
| Specification | |
| Rated Lifting Weight | 2500kg |
| Rated Lifting Height | 3000-6000mm |
| Load Center Distance | 500mm |
| Mast Tilt Angle(Forward/Backward) | 12°/15° |
| Minimum Turning Radius | 2350mm |
| Climbing Ability(Empty/Full) | 13°/15° |
| Minimum Mast Height | 2130mm |
| Free Lift Height | 140mm |
| Maximum Mast Height | 3960mm |
| Mast Type | 12# National Standard Section Steel |
| Main Dimensions | |
| Overall Dimensions(L*W*H) | 2460*1210*2100mm |
| Standard Fork Length | 1220mm |
| Minimum Ground Clearance Of Mast | 110mm |
| Minimum Ground Clearance Of Frame | 120mm |
| Overhead Guard Height | 2100mm |
| Seat Height | 970mm |
| Rear And Rear Wheelbase | 1690mm |
| Tire Spacing | Front Track 1020mm, Rear Track 930mm |
| Overhang | 470mm |
| Performance | |
| Front Axle | Mid-Range Cast Steel Axle |
| Tires | Front Tire 650-10, Rear Tire 500-8, Class C |
| Rear Axle | Steel Plate Bridge |
| Braking Method | Hydraulic Brake |
| Drive Motor Controller | 5kw |
| Lift Motor Controller | 5kw |
| Operating Voltage | 60V |
| Standard Battery Capacity | 10*140AH |
| Overall Weight | 3050kg |
